Acid and alkali resistant belt conveyor acid and alkali resistant 304 stainless steel idler conveyor idler high life idl

Chang Hong Mining Machinery Co., Ltd.
Contact Now
    Buy cheap Acid and alkali resistant belt conveyor acid and alkali resistant 304 stainless steel idler conveyor idler high life idl from wholesalers

    Buy cheap Acid and alkali resistant belt conveyor acid and alkali resistant 304 stainless steel idler conveyor idler high life idl from wholesalers
    • Buy cheap Acid and alkali resistant belt conveyor acid and alkali resistant 304 stainless steel idler conveyor idler high life idl from wholesalers
    • Buy cheap Acid and alkali resistant belt conveyor acid and alkali resistant 304 stainless steel idler conveyor idler high life idl from wholesalers

    Acid and alkali resistant belt conveyor acid and alkali resistant 304 stainless steel idler conveyor idler high life idl

    Ask Lasest Price
    Brand Name : Changhong
    Model Number : 110*465
    Certification : ISO
    Price : $40.00 /Piece | 1 Piece
    Payment Terms : Western Union, T/T
    Supply Ability : Annual production of 1000000 pieces
    • Product Details
    • Company Profile

    Acid and alkali resistant belt conveyor acid and alkali resistant 304 stainless steel idler conveyor idler high life idl

    Mining industry belt conveyor carrying idler impact roller

    Acid and alkali resistant belt conveyor acid and alkali resistant 304 stainless steel idler conveyor idler high life idl

    Roller is an important component of belt conveyor.It has many kinds and large quantity,can support conveyor belt and material weight.

    Product Specification
    Item Mining industry belt conveyor carrying idler impact roller
    Diameter 89-159mm
    Length 190-1500mm
    Material Carbon steel
    Seal Multiple labyrinth seal
    Bearing type Deep Grove ball bearing
    Gurantee 12 months
    Color Customized
    Certificate ISO,CE
    Advantages waterproof,dustproof,smooth running,no noise,rotational resistance, axial float, shaft radial play

    Features:

    A) Bearing: deep groove ball and double sealing bearing 2RZ and 2Z with C3 clearance;

    B) Sealing: multi-stage labyrinth seals achieve waterproof and dust proof

    C) Lubrication: Grease is Lithium soap type grease with Rust Inhibitors, grease is permanent lubricant.

    D) Color: roller surface could be painted any color as per customer request.

    E) Each roller would be through strict inspection and test to ensure every out coming roller is of true high quality;

    Technology Specification
    D d

    Bearing

    Model

    L b h f

    Weight

    (kg)

    D d

    Bearing

    Model

    L b h f

    Weight

    (kg)

    89 20 4G204 200 14 6 14 2.79 133 25 4G205 380 18 8 17 7.84
    250 2.98 465 9.24
    315 3.58 600 11.48
    465 5.24 700 13.44
    600 6.48 1150 20.6
    750 7.87 1400 24.61
    950 9.72 4G305 380 8.21
    25 4G205 8 18 17 11.21 465 9.62
    108 20 4G204 315 14 6 14 4.46 530 10.7
    465 6.07 600 11.86
    950 11.27 700 13.51
    25 4G205 315 18 8 17 5.07 800 15.17
    380 5.86 1150 20.97
    465 6.89 1400 24.99
    600 8.53 1600 28.44
    700 9.74 30 4G306 465 11.34
    950 12.77 530 12.54
    1150 13.99 800 17.48
    1400 15.62 1400 26.75
    4G305 380 6.23 1600 31.38
    465 7.26 159 25 4G205 465 11.58
    530 8.05 700 16.52
    600 8.9 1400 31.09
    700 10.11 4G305 465 12.02
    800 11.32 530 13.84
    950 13.14 700 16.95
    1150 15.57 800 19.06
    1400 18.47 1400 31.52
    1600 21.02 1600 35.85
    30 4G306 465 22 8.57 30 4G306 465 22 13.76
    530 9.47 530 15.23
    800 13.2 800 21.36
    1400 21.49 1400 34.98
    1600 24.26 1600 39.51


    Quality design and build

    Our focus on quality starts with sourcing only the best raw materials, rejecting anything that falls outside our strict tolerances.During manufacture your order is checked at each stage before passing through to the next process. This also contributes to our ability to meet orders on time.

    Mining industry belt conveyor carrying idler impact roller

    Mining industry belt conveyor carrying idler impact roller

    Mining industry belt conveyor carrying idler impact roller
